1101VT

Typical Specifications

1. Rating : DC12V 50mA
2. Travel : 0.25±0.1mm
3. Contact Resistance : 100mΩMax.
4. Bounce : 10m SEC MAX.
5. Operating Force
* DJT1101VT-1 : 130±30gf [50,000Cycle]
* DJT1101VT-2 : 180±50gf [50,000Cycle]
* DJT1101VT-3 : 250±
