1109

Typical Specifications

1. Rating : DC12V 50mA
2. Travel : 0.25±0.1mm
3. Contact Resistance : 100mΩMax.
4. Bounce : 10m SEC MAX.
5. Operating Force
* 1109-0 : 100±30gf [1,000,000Cycle]
* 1109-1 : 130±30gf [500,000Cycle]
* 1109-2 : 180±50gf [100,0
