2220

Typical Specifications

1.Rating : DC30V 0.1A
2.Circuit : 4C – 2P
3.Contact Resistance : 50mΩMax.
4.Timing : NON-SHORTING
5.Operating Mode :
* SELF-LOCK
* NON-LOCK
6.Storke :
*FULL : 1.7mm
*LOCK : 1.2mm
7.Operating Force : 250±80gf
8.Operatin
